Rendering 2 (2020_10_05 00_21_10 UTC).jpg

DURCO G4Z11 (F).JPG
Durco G4 Cut Away.jpg


Fort Vale PFA Lined Ball Valve

The preferred fluoropolymer lined valve for transportation.

Features:

·       Stainless Steel Body

·       PFA Lined Body

·       PFA Lined Stainless Steel Ball & Stem

·       PFA Lined Clamp Plate

·       PFTE Front & Rear Seal & O-Ring

·       Self Adjusting Stem Seal

·       Low Profile

·       Ultra low torque design

·       Ultra high flow

·       Repairable

Specifications

·       AAR Number             2” E222122 / 3” E222123

·       Size Range                2” – 3”

·       Materials                   Stainless Steel Body & Stem



Durco G4 Valves

G4Z11 Features:

·       Positive Stem Seal

·       In-Line / Thru-Line Seal Adjustability

·       Line Sealing

·       API 607 Certified

·       Low fugitive emissions

·       Low torque design

·       Steam Jacket Available

·       Threaded Flange Available

·       3 Year Warranty

Specification

·       AAR Number

·       Size Range                  1” – 3”

·       Materials                    304 Stainless Steel Body / 304 Stainless Plug Valve
